Shot Blasting

Suction Blasting Cabinet

4.9 28 reviews
Suction Blasting Cabinet

Enquire now

Request a quotation

Shot Blasting In stock · Factory tested

Suction Blasting Cabinet

Engineering reply within one business day · Domestic & export supply

Indicative range ₹70 K - 3.5 Lakh Final quote depends on configuration & destination
+91-8690066649 WhatsApp

Datasheet

Technical & commercial data

Specifications

Storage Capacity
28 - 42 Lit.
Req. Compressed air (80 psi)
17 - 20 CFM
Cleaning Rate
4 - 15 Sq. Mtr./Hr.
Nozzle
Tungsten / Boron Carbide
Nozzle Size
6 mm - 8 mm
Dust Collector
Fabric Bag / Pleated Filter Type
Brand
Micro Blaster
Cabinet Type
Suction Blasting
Material
Mild Steel
Accessory
Pressure Gauge, Air Regulator & Moisture Separator fitted Foot Switch & Door limit switch
Recommended Abrasive Size
30 - 220 Mesh

Where it is used

Applications

Typical process uses for Suction Blasting Cabinet across industrial surface preparation.

Depending on the type of blastings required, such as shot or sand blasting, the Suction Blasting Cabinet uses a variety of abrasives to remove impurities and rust.

The Suction Blasting Cabinet provides an environmentally friendly blasting method for abrasive blasting since it collects all the tiny particles from the abrasive medium into the Dust Collector.

The suction blasting cabinet's use of glass beads gives the metal object a brilliant finish.

In small places, suction blasting cabinets are used to finish, texture, and clean surfaces while safeguarding both the environment and workers.

What to know

Product details

Overview

Suction shot Blasting Cabinet is based on the Injection Suction principle of blasting. The industrial shot blast cabinet ensures non-stop working and no interruption in the blasting cycle. It is used for light and medium-size components / particles where the surface is to be cleaned or debarred or to provide a fine matte finish. The suction cabinet works on the Venture system to get abrasive from a non-pressurized storage sand blasting hopper to the blast gun where it is mixed with the compressed air stream and impelled on the work surface or blasting surface.

Enquiry form

Request a quotation

Fields marked with * are required.

Typical response within one business day. Your details are used only for this quotation.

FAQ

Answers before you buy

Quick clarity on quotation, supply and what our team needs to size Suction Blasting Cabinet correctly.

What is Suction Blasting Cabinet?

Suction Blasting Cabinet is a surface preparation system that uses compressed air or a blast wheel to propel abrasive media against metal components. It is built for industrial cleaning, descaling, deburring and profile generation before painting or coating.

What applications suit Suction Blasting Cabinet?

Suction Blasting Cabinet is used where repeatable blast quality, controlled dust handling and efficient media recovery matter — such as fabrication shops, OEM plants, job-coating units and maintenance yards. Share your part size and daily volume for application-specific sizing.

How do I get an accurate price for Suction Blasting Cabinet?

Provide component dimensions, required finish (e.g. Sa 2.5), estimated throughput, power availability and delivery location. We quote the correct configuration with installation scope, spare parts and commercial terms — not an off-the-shelf brochure price.

Do you install and support Suction Blasting Cabinet after supply?

Yes. Micro Blaster supports commissioning guidance, operator orientation, wear-part supply and technical assistance for Suction Blasting Cabinet. Domestic installation and export documentation can be arranged based on project scope.

How soon will I get a response for Suction Blasting Cabinet?

Product enquiries for blasting equipment typically receive a technical and commercial reply within one business day. Drawings, photos or sample parts help us recommend the right model faster.
