Grit Blasting Room

Grit blasting Booth Recovery System is two types- mechanical and vacuum In the vacuum recovery system compressed air is used for transfer grit and In automatic recovery system during grit, grit blasting abrasive falls.

Dust collectors are used for dust collecting during grit blasting in a blast booth. A portable blasting machine is placed outside of the Gritblasting booth and the operator can do blasting inside the enclosure by blasting hose. A portable grit blaster machine is automatically on-off by remote control and deadman handle in the Grit blasting room.

Recovery System is two types- mechanical and vacuum In vacuum recovery system compressed air is used for transfer grit and In automatic recovery system during grit, grit blasting abrasive comes down in screw conveyor and then media is transferred in bucket elevator, bucket elevator separate usable shot and non-usable by media separator, Usable shots fall down in grit blasting hopper and this process will continue.

During Grit blasting operation operator wears safety wear which is protected from accelerated grits or sand.  Blast room can Steel Construction or Civil Constructed, in Civil constructed blast room door will be mild steel fabricated with air louvers, Air louvers enter required air as per dust collection system. Blast Room System door can be sliding and hinged type, we can supply according to customer need and space available at customer workshop.

Dust Collection of blasting booth several types, most popular is Cyclone Type dust collector, Motorized shaking type, Reverse Pulse jet Pleated filter. We supply a dust collection system as per the client’s needs & specifications of components. Grit blasting Chamber design is customized as per customer need its can fully automatic, Semi-automatic or manually type.

Dust Collectors

Metallic Blast Room Construction: The metallic blast room is a fully sealed, dust-tight, all-steel structure, viable to be manufactured in varying sizes. The panels are prefabricated for a simple bolt-together erection on site. Blast Room Enclosure is based on this design to meet the majority of customers’ requirements.

Blast Room System Includes Following Features:
