Automatic Sand Blasting Machine

The Automatic Sand Blasting Machine has two stepper motor first motor is used for rotating the table and the second motor has used for the moving up and down the gun by reciprocating movement. In the Sand blasting Machine workpiece is put on the turntable and rotating through the stepper motor first and through the second motor we can change the Sand Blasting nozzles position up and down, on the control panel have four switches. through switches, we can change the Sand Blasting nozzle position like 154, 250, 305, 355mm. on the control panel has a switch through this switch we can on/off the Automatic Sand blasting process. and also we control the speed of the table rotating through the regulator switch. Initially start the air compressor. and fill the abrasive material in the Automatic Sandblasting cabinet and workpiece put into the Automatic Sand Blasting Cabinet on the turntable. the air compressor provides a large volume of high-pressure air that is controlled by the Solenoid valve or ball valve. Solenoid valves are used wherever fluid and airflow are to be controlled automatically. After that Non-return valve is used for providing safety to the moisture separator. the ball valve is controlled by the operators manually (On/Off).  Air compressor air enters the suction gun through the Pipe If the Ball Valve is on then the vacuum creates in the gun due to this occasion creates suction in the gun. abrasive materials propellers on the abrasive surface through the gun. through air compressor directly air provided on the mixing tube for high speed propelling. blaster surface and blaster media both have lived in the cabinet. The automatic Sand Blasting Machines is a dust-free environment.  We have a Fabric Bag Dust collector at the backside of the Automatic Blasting Cabinet to collect dust particles in the form of dust & microparticles get to settle down use as recycle abrasives. There are two ways of blasting the workpiece by moving the workpiece or by moving a Sand Blasting gun.
